Sonarworks SoundID Ref Multichannel w Mic

Bundle of Measuring Microphone and Software

• For speaker and headphone calibration
• Reference sound for speaker setups from stereo to 9.1.6 Atmos systems
• Frequency response correction for studio monitors and headphones for the most linear reproduction possible
• Enables better assessment of recordings and mixes
• Room analysis and automatic room size calculation using numerous measuring points
• Audio Calibration Engine for the most accurate adjustment possible
• Any number of profiles for speakers can be stored
• Provides calibration curves for over 480 different headphone models
• Target curves can be individually adjusted in real time
• 3 Selectable filter modes: Zero Latency, Mixed and Linear Phase to optimise filter quality and latency for different listening situations
• Additional settings for mono, dry/wet and safe headroom
• Only available in the app: MIDI mapping for various parameters and user presets for predefined output configurations
• Export of calibration profile to supported hardware
• Measurement microphone with pre-polarised electret condenser capsule
• Frequency range: 20 - 20000 Hz with measurement protocol
• Polar pattern: omnidirectional
• Sensitivity: 14mV / Pa
• Inherent noise: 24 dB
• Signal-to-noise ratio: 70 dB
• Dynamic range: 106dB
• Limiting sound pressure level: 132 dB SPL
• Requires 48V phantom power
• Connector: XLR 3-pin
• Multi-angle calibration curves
