Shure SM 86

Vocal Condenser Microphone

The Shure SM86 is a condenser microphone with cardioid polar pattern for professional live use. The robust condenser microphone can withstand every stressing situation on stage, and still provides studio quality. The matched frequency response of the SM86 provides a precise reproduction of the voice, and the cardioid polar pattern, pointing directly to the signal source, ensures a almost noise-free signal. The built-in three-point shock absorber reduces handling noise, while the two-layer windscreen minimizes wind and pop noise. The SM86 is an excellent choice for both stage and in-ear monitoring.

• Optimized for singing
• Studio quality condenser capsule
• Matched frequency response for precise reproduction of vocals.
• Extremely robust design withstands extreme loads.
• Cardioid polar pattern reduces unwanted background noise.
• Excellent for use with stage and in-ear monitoring.
• Built-in three-point shock absorber reduces handling noise.
• Two-layer windscreen reduces wind and pop noise.
• Frequency range: 50 Hz - 18 kHz
• Output impedance: 150 O
• Open circuit sensitivity: -50 dBV/ Pa (3.15 mV)
• Max. SPL (at 1 kHz, 1 kO load, 0.1% THD): 147 dB
• Inherent self-noise (equivalent noise level): 23 dB(A)
• Power supply: 11 to 52 V
• Power consumption: 5.2 mA
• Dimensions (L x ?): 183 x 49 mm
• Weight: 278 g
